Onze bevestigingssystemen vergeleken

De Quick-Lock-bevestigingssystemen van de ORTLIEB fietstassen maken het mogelijk om de tassen snel en veilig aan de bagagedrager te bevestigen. Ze worden ook zelfvergrendelende bevestigingssystemen genoemd, omdat fietstassen met dit systeem eenvoudig en veilig aan de bagagedrager kunnen worden gehangen. Alle bevestigingsonderdelen zijn bij beschadiging zeer eenvoudig te vervangen.

Bevestigingssysteem

Quick-Lock3.1

Bevestigingssysteem

Quick-Lock2.2

Bevestigingssysteem

Quick-Lock2.1

The QL3.1 system secures the bag to the rack particularly quickly and easily and offers excellent carrying comfort away from the bike.

The evolution of the QL2.1 system, with higher payload and quick switching between different bikes.

ORTLIEB’s most proven mounting system, trusted by millions of satisfied cyclists.

Kenmerk

Back of bag is free of protruding hooks
Quick, tool-free adjustment without reducer inserts
Tool-free adjustment

Maximaal laadvermogen

9 kg
12.5 kg
9 kg

Compatibele bagagedragers

For racks with QL3.1-compatible mounting points. Can also be retrofitted with the QL3.1 Mounting Set.

Compatible with all conventional luggage racks

Compatible with all conventional luggage racks

Compatibele buisdiameters

8–16 mm (with QL3.1 Mounting Set)
8–20 mm
8–20 mm

The QL3.1 Mounting Set can be attached to racks with a tube diameter of up to 16 mm. For tube diameters from 11 to 16 mm, the adapter clamps are also required.

The hooks can be adjusted tool-free between 10 and 16 mm in 1 mm increments. With the QL2.1 hooks, 18 or 20 mm tubes can also be used.

The 16 mm hooks can be adjusted to 8, 10 and 12 mm using the included reducer inserts. With the QL2.1 hooks and anchoring hooks, 18 or 20 mm tubes can also be used.

Meer eigenschappen

Afsluitbaar

with the QL2-Lock or the anti-theft device

(not included)

with the QL2-Lock or the anti-theft device

(not included)

Met één hand te bedienen

Bevestigingsonderdelen

On the rack
On the bag
On the bag

Anti-krascoating

Not necessairy

On upper hooks, lower hooks & lower hook rail

On reducer inserts (upper hooks) & lower hook rail

Alle afzonderlijke onderdelen zijn als reserveonderdeel verkrijgbaar
